Interior wall Insulation Steel stud interior wall

ROCKWOOL AFB®

ROCKWOOL AFB is a stone wool batt insulation designed for interior partitions in steel and wood stud commercial construction.

The best mix of fire resistance, sound absorption, and durability an insulation has to offer.

Back
Back

Specifications & sizes

Compliance Type 1 Compliant Mineral Fiber Insulation, MEA Approval
CAN/ULC S702 Mineral Fiber Thermal Insulation for Buildings, Type 1 Compliant
ASTM C665 Mineral Fiber Blanket Thermal Insulation, Type 1 Compliant
ASTM C553 Mineral Fiber Blanket Thermal Insulation, Type 7 Compliant
338-97-M MEA Approval, New York City Approval
RR 25444 City of Los Angeles Approval
Density > 2.5 lbs/ft3 (> 40 kg/m3 )
ASTM C303 Actual Density at thicknesses < 3" (76.2 mm) - 2.8 lb/ft³ (45 kg/m³)
Dimensions Thickness – 1” – 6” (25.4 mm – 152.4 mm)
16" x 48" (413 mm x 1219 mm)
24" x 48" (610 mm x 1219 mm)
Reaction to fire Non-combustible, Flame Spread = 0, Smoke Development = 0
ASTM E84 (UL 723) Flame spread index = 0 ; Smoke developed index = 0
CAN/ULC S102 Flame spread index = 0 ; Smoke developed index = 0
CAN/ULC S114 Determination of Non-Combustibility of Building Materials - Non-Combustible
ASTM E136 Behavior of materials at 750°C - Non-Combustible
CAN/ULC S129

Smolder Resistance - 0.09%

Acoustical Performance NRC = 1.05 (3” thickness)
Thickness 125 Hz 250 Hz 500 Hz 1000 Hz 2000Hz 4000 Hz NRC
1.0" 0.14 0.25 0.65 0.9 1.01 1.01 0.7
1.5" 0.18 0.44 0.94 1.04 1.02 1.03 0.85
2" 0.28 0.6 1.09 1.09  1.05 1.07 0.95
3" 0.52 0.96 1.18 1.07 1.05 1.05 1.05
4" 0.86 1.11 1.2 1.07 1.08 1.07 1.1
Back
CAN/ULC S702 Mineral Fiber Thermal Insulation for Buildings, Type 1 Compliant
ASTM C665 Mineral Fiber Blanket Thermal Insulation, Type 1 Compliant
ASTM C553 Mineral Fiber Blanket Thermal Insulation, Type 7 Compliant
338-97-M MEA Approval, New York City Approval
RR 25444 City of Los Angeles Approval
Back
ASTM C303 Actual Density at thicknesses < 3" (76.2 mm) - 2.8 lb/ft³ (45 kg/m³)
Back
16" x 48" (413 mm x 1219 mm)
24" x 48" (610 mm x 1219 mm)
Back
ASTM E84 (UL 723) Flame spread index = 0 ; Smoke developed index = 0
CAN/ULC S102 Flame spread index = 0 ; Smoke developed index = 0
CAN/ULC S114 Determination of Non-Combustibility of Building Materials - Non-Combustible
ASTM E136 Behavior of materials at 750°C - Non-Combustible
CAN/ULC S129

Smolder Resistance - 0.09%

Back
Thickness 125 Hz 250 Hz 500 Hz 1000 Hz 2000Hz 4000 Hz NRC
1.0" 0.14 0.25 0.65 0.9 1.01 1.01 0.7
1.5" 0.18 0.44 0.94 1.04 1.02 1.03 0.85
2" 0.28 0.6 1.09 1.09  1.05 1.07 0.95
3" 0.52 0.96 1.18 1.07 1.05 1.05 1.05
4" 0.86 1.11 1.2 1.07 1.08 1.07 1.1

Product Range

Country

Thickness (inch)

Construction

Product

Item number Product Country Thickness (inch) Width (inch) Length (inch) Pieces Per Pack Packs Per Pallet Square Feet Per Pack Square Feet Per Pallet Construction
291319 AFB Canada 1 16 48 32 11 73.14 2048 Steel Stud
168672 AFB Canada 1.5 24 48 16 12 59.08 1536 Steel Stud
291318 AFB Canada 1.5 16 48 18 12 41.14 1152 Steel Stud
168648 AFB Canada 2 24 48 12 12 44.31 1152 Steel Stud
291322 AFB Canada 2 16 48 16 12 36.57 1024 Steel Stud
168652 AFB Canada 2.5 24 48 10 12 36.92 960 Steel Stud
291321 AFB Canada 2.5 16 48 12 12 27.43 768 Steel Stud
168650 AFB Canada 3 16 48 8 12 29.54 768 Steel Stud
291326 AFB Canada 3 16 48 12 12 27.43 768 Steel Stud
273583 AFB Canada 3.5 24 48 8 12 29.54 768 Steel Stud
291324 AFB Canada 3.5 16 48 12 10 27.43 768 Steel Stud
168656 AFB Canada 4 24 48 6 12 576 Steel Stud
291327 AFB Canada 4 16 48 8 10 18.29 512 Steel Stud
168661 AFB Canada 5 24 48 5 12 18.46 480 Steel Stud
291328 AFB Canada 5 16 48 6 12 13.71 384 Steel Stud
168659 AFB Canada 6 24 48 4 12 14.77 384 Steel Stud
291329 AFB Canada 6 16 48 6 12 13.71 384 Steel Stud
168671 AFB USA 1 24 48 24 12 88.62 2304 Steel Stud
291319 AFB USA 1 16 48 32 12 73.14 2048 Steel Stud
291318 AFB USA 1.5 16 48 18 12 41.14 1152 Steel Stud
168648 AFB USA 2 24 48 12 12 44.31 1152 Steel Stud
291322 AFB USA 2 16 48 16 12 36.57 1024 Steel Stud
168652 AFB USA 2.5 24 48 10 10 36.92 960 Steel Stud
291321 AFB USA 2.5 16 48 12 12 27.43 768 Steel Stud
286368 AFB USA 3 24 48 10 12 36.92 960 Steel Stud
291183 AFB USA 3 16 48 16 12 36.57 1023.9 Steel Stud
291279 AFB USA 3 15 48 16 12 34.29 960 Wood Stud
294432 AFB USA 3 23 47 10 12 34.65 900.84 Wood Stud
294401 AFB USA 3 19 47 10 12 28.92 752.04 I-Joist
286386 AFB USA 3.5 24 48 8 12 29.54 768 Steel Stud
291276 AFB USA 3.5 16 48 12 12 27.43 768 Steel Stud
294407 AFB USA 3.5 15 47 12 12 25.6 716.76 Wood Stud
294410 AFB USA 3.5 23 47 8 12 27.72 720.72 Wood Stud
286390 AFB USA 4 24 48 8 12 29.54 768 Steel Stud
291280 AFB USA 4 16 48 12 12 27.43 768 Steel Stud
286392 AFB USA 5 24 48 6 12 22.15 576 Steel Stud
291281 AFB 5 16 48 8 12 18.29 512.04 Steel Stud
286447 AFB USA 6 24 48 5 12 18.46 480 Steel Stud
291282 AFB USA 6 16 48 8 12 18.29 512.04 Steel Stud
294405 AFB USA 6 19 47 5 12 14.46 375.96 I-Joist
248651 AFB evo 1 24 48 24 48 88.62 2304 Steel Stud
248812 AFB evo 1.5 24 48 16 12 59.08 1536 Steel Stud
291333 AFB evo 1.5 16 48 16 48 41.14 1152 Steel Stud
248817 AFB evo 2 24 48 12 12 44.31 1152 Steel Stud
291334 AFB evo 2 16 48 16 12 36.57 1024 Steel Stud
248821 AFB evo 2.5 24 48 10 12 36.92 960 Steel Stud
231121 AFB evo 3 24 48 8 12 29.54 768 Steel Stud
291336 AFB evo 3 15 48 12 12 25.71 720 Steel Stud
291337 AFB evo 3 16 48 12 12 27.43 768 Steel Stud
274563 AFB evo 3.5 24 48 8 12 29.54 768 Steel Stud
291335 AFB evo 3.5 16 48 12 12 27.43 768 Steel Stud
