The BEAMCLAD Systems are fire tested insulation solutions for structural steel, concrete and timber construction. Offering contractors simple and cost effective fire protection solutions, the mineral wool insulation has been specially designed to suit steel construction, including structural soffit protection.
Benefitting from a choice of installation methods, ROCKWOOL BEAMCLAD boards can be fitted utilising dry joint solutions offering up to 3 hours fire protection, or glued joint solutions where extended protection up to 4 hours is required.
Designed and tested to provide essential passive fire protection, BEAMCLAD Systems also have the added benefit of providing thermal insulation to minimise cold bridging and acoustic benefits to minimise the transfer of vibrations through the structure of the building.
|NBS Clause||Length (mm)||Width (mm)||*Approved thicknesses (mm)|
K11 Rigid sheet flooring / sheathing / decking / sarking / linings / casings
*Thickness options may be subject to a minimum production volume. Speak to the Customer Support Centre for guidance.
Standards and Certification
|Product standards||Tested and assessed to ENV 13381-4:2002 and EN 13381-4:2013|
|LUL||The product has been authorised for use in LUL surface and sub-surface premises (LUL Ref: 2221) when installed in accordance with the data sheet.|
|Reaction to fire (Euroclass)||Euroclass A1|
|Fire resistance||Up to 4 hours|
|Density||167 – 180kg/m3|
|System||Fire resistance (mins)|
|Glued noggins, glued application, glued board joints||×||×||×||×||×||×|
|Welded pins, glued board joints||×||×||×||×||×||×|
|Welded pin, dry board joints||×||×||×||×||×|
Download CAD Drawings here
