RAINSCREEN DUO SLAB®
RAINSCREEN DUO SLAB ® is a stone wool insulation product specifically developed for use within ventilated cladding systems, as well as sealed systems such as curtain walling.
Manufactured using Dual Density technology, the outer surface of each slab features a distinctly higher density than the underside. This provides a firm and robust surface for the application of fixings, while the resilient underside can accommodate unevenness in the substrate.
Once installed, the higher density outer surface works in combination with a factory-applied water repelling agent to give improved resistance to rain ingress during construction.
As demonstrated by independent in-situ laboratory testing, RAINSCREEN DUO SLAB helps to reduce the transfer of airborne noise - with results for typical systems as high as Rw 62 dB. For more information please see the Rainscreen Acoustic Reference Guide.
|NBS Clause||Length (mm)||Width (mm)||*Approved thickness range (mm)|
H11 – 110
H11 – 780
H92 – 776
P10 – 217
|1200||600||50 – 230|
*Thickness options may be subject to a minimum production volume. Speak to the specification team for guidance.
Standards and Certification
|Product standards||BS EN 13162|
|CE Marking||CE Marked|
|BBA Approved||Certificate 17/5042|
|Reaction to fire (Euroclass)||A1 (BS EN 13501-1)|
|Thermal conductivity||0.034 W/mK (<90mm) / 0.035 W/mK (≥90mm)|
|Water vapour resistance||5.9MNs/gm|
|RAINSCREEN DUO SLAB®||Steel Frame Slab|
- Sound reduction up to 62 Rw
- Tested as part of a through wall build-up.
- Assessed against the data held within test report C/23666/T03
Download CAD Drawings here
